LinkElementCommand Class Reference

The LinkElementCommand class This undo class manage link between elements. In the same instance of this class, we can link and unlink elements from an edited element This undo class support the merge. More...

#include <linkelementcommand.h>

Inherits QUndoCommand.

Collaboration diagram for LinkElementCommand:

Public Member Functions
	LinkElementCommand (Element *element_, QUndoCommand *parent=nullptr)
	LinkElementCommand::LinkElementCommand Constructor.
int	id () const override
bool	mergeWith (const QUndoCommand *other) override
	LinkElementCommand::mergeWith.
void	setLink (const QList< Element * > &element_list)
	LinkElementCommand::setLink Replace all linked elements of edited element by elements stored in element_list This method do several check to know if element can be linked or not.
void	setLink (Element *element_)
	LinkElementCommand::setLink This is an overloaded function.
void	unlink (QList< Element * > element_list)
	LinkElementCommand::unlink Unlink all elements of element_list from the edited element.
void	unlinkAll ()
	LinkElementCommand::unlinkAll Unlink all element of the edited element.
void	undo () override
	LinkElementCommand::undo Undo this command.
void	redo () override
	LinkElementCommand::redo Redo this command.

Static Public Member Functions
static bool	isLinkable (Element *element_a, Element *element_b, bool already_linked=false)
	LinkElementCommand::isLinkable.

Private Member Functions
void	setUpNewLink (const QList< Element * > &element_list, bool already_link)
	LinkElementCommand::setUpNewLink Update the content of m_link_after with the content of element_list. Each linkable element (know via the static method isLinkable) is added to m_linked_after already_link is used for the static method isLinkable.
void	makeLink (const QList< Element * > &element_list)
	LinkElementCommand::makeLink Make the link between m_element and element_list; This method unlinks elements if needed.

Private Attributes
Element *	m_element
bool	m_first_redo
QList< Element * >	m_linked_before
QList< Element * >	m_linked_after

Detailed Description

The LinkElementCommand class This undo class manage link between elements. In the same instance of this class, we can link and unlink elements from an edited element This undo class support the merge.

Constructor & Destructor Documentation

LinkElementCommand()

LinkElementCommand::LinkElementCommand	(	Element *	element_,
		QUndoCommand *	parent = nullptr
	)

LinkElementCommand::LinkElementCommand Constructor.

Parameters

element_	: element where we work the link / unlink
parent	: parent undo

Here is the call graph for this function:

Member Function Documentation

id()

int LinkElementCommand::id ( ) const

inlineoverride

isLinkable()

bool LinkElementCommand::isLinkable ( Element *  element_a, Element *  element_b, bool  already_linked = false  )

static

LinkElementCommand::isLinkable.

Parameters

element_a
element_b
already_linked

Returns

true if element_a and element_b can be linked between them. There is few condition to be linked : 1- element_a and element_b must be linkable type. (Ex : A is master and B is slave 'OK', A and B is master 'KO') 2- For element type slave and report (no matter if element is 'A' or 'B'), the element must be free (not connected to an element) 3- we can override the section 2 by set already_linked to true. In this case, if slave or report is already linked to the other element ('A' or 'B') return true, but if linked to another element (not 'A' or 'B') return false

Here is the call graph for this function:

Here is the caller graph for this function:

makeLink()

void LinkElementCommand::makeLink ( const QList< Element * > &  element_list )

private

LinkElementCommand::makeLink Make the link between m_element and element_list; This method unlinks elements if needed.

Parameters

element_list

Here is the call graph for this function:

Here is the caller graph for this function:

mergeWith()

bool LinkElementCommand::mergeWith ( const QUndoCommand *  other )

override

LinkElementCommand::mergeWith.

Parameters

other

try to merge this command with other

Returns

true if merge with success else false

Here is the call graph for this function:

redo()

void LinkElementCommand::redo ( )

override

LinkElementCommand::redo Redo this command.

Here is the call graph for this function:

setLink() [1/2]

void LinkElementCommand::setLink

(

const QList< Element * > &

element_list

)

LinkElementCommand::setLink Replace all linked elements of edited element by elements stored in element_list This method do several check to know if element can be linked or not.

Parameters

element_list

Here is the call graph for this function:

Here is the caller graph for this function:

setLink() [2/2]

void LinkElementCommand::setLink

(

Element *

element_

)

LinkElementCommand::setLink This is an overloaded function.

Parameters

element_

Here is the call graph for this function:

setUpNewLink()

void LinkElementCommand::setUpNewLink ( const QList< Element * > &  element_list, bool  already_link  )

private

LinkElementCommand::setUpNewLink Update the content of m_link_after with the content of element_list. Each linkable element (know via the static method isLinkable) is added to m_linked_after already_link is used for the static method isLinkable.

Parameters

element_list
already_link

Here is the call graph for this function:

Here is the caller graph for this function:

undo()

void LinkElementCommand::undo ( )

override

LinkElementCommand::undo Undo this command.

Here is the call graph for this function:

Here is the caller graph for this function:

unlink()

void LinkElementCommand::unlink

(

QList< Element * >

element_list

)

LinkElementCommand::unlink Unlink all elements of element_list from the edited element.

Parameters

element_list

unlinkAll()

void LinkElementCommand::unlinkAll

(

)

LinkElementCommand::unlinkAll Unlink all element of the edited element.

Here is the caller graph for this function:

Member Data Documentation

m_element

Element* LinkElementCommand::m_element

private

m_first_redo

bool LinkElementCommand::m_first_redo

private

m_linked_after

QList<Element *> LinkElementCommand::m_linked_after

private

m_linked_before

QList<Element *> LinkElementCommand::m_linked_before

private

---

The documentation for this class was generated from the following files:

• sources/undocommand/linkelementcommand.h
• sources/undocommand/linkelementcommand.cpp
