ModifyTemplateGridCommand Class Reference

#include <templatecommands.h>

Inheritance diagram for ModifyTemplateGridCommand:

Collaboration diagram for ModifyTemplateGridCommand:

Public Member Functions
	ModifyTemplateGridCommand (TitleBlockTemplate *=nullptr, QUndoCommand *=nullptr)
	~ModifyTemplateGridCommand () override
int	index () const
void	setIndex (int)
QList< TitleBlockCell * >	cells () const
void	setCells (const QList< TitleBlockCell * > &)
TitleBlockDimension	dimension () const
void	setDimension (const TitleBlockDimension &)
int	type () const
void	setType (bool)
bool	isInsertion () const
void	setInsertion (bool)
void	undo () override
void	redo () override
Public Member Functions inherited from TitleBlockTemplateCommand
	TitleBlockTemplateCommand (TitleBlockTemplate *=nullptr, QUndoCommand *=nullptr)
	~TitleBlockTemplateCommand () override
TitleBlockTemplate *	titleBlockTemplate () const
void	setTitleBlockTemplate (TitleBlockTemplate *)
TitleBlockTemplateView *	view () const
void	setView (TitleBlockTemplateView *)
void	refreshView ()
void	refreshLayout ()

Static Public Member Functions
static ModifyTemplateGridCommand *	addRow (TitleBlockTemplate *, int=-1)
static ModifyTemplateGridCommand *	addColumn (TitleBlockTemplate *, int=-1)
static ModifyTemplateGridCommand *	deleteRow (TitleBlockTemplate *, int=-1)
static ModifyTemplateGridCommand *	deleteColumn (TitleBlockTemplate *, int=-1)

Private Member Functions
	ModifyTemplateGridCommand (const ModifyTemplateGridCommand &)
void	updateText ()
void	apply (bool=false)

Private Attributes
int	index_
	Index of the inserted/deleted row/column.
QList< TitleBlockCell * >	cells_
	Cells composing the inserted/deleted row/column.
bool	type_
	true for a row, false for a column
TitleBlockDimension	dimension_
	width/height of the column/row, which interpretation depends on type_
bool	insertion_

Additional Inherited Members
Protected Attributes inherited from TitleBlockTemplateCommand
TitleBlockTemplate *	tbtemplate_
	Modified TitleBlock Template.
TitleBlockTemplateView *	view_
	This class may trigger a view update.

Detailed Description

This class represents the action of adding or deleting a row or column within a title block template.

Constructor & Destructor Documentation

ModifyTemplateGridCommand() [1/2]

ModifyTemplateGridCommand::ModifyTemplateGridCommand	(	TitleBlockTemplate *	tbtemplate = nullptr,
		QUndoCommand *	parent = nullptr
	)

Construct a default ModifyTemplateGridCommand, i.e. a command adding a 25px row at the bottom of the template.

Parameters

tbtemplate	Modified title block template
parent	Parent QUndoCommand

Here is the call graph for this function:

~ModifyTemplateGridCommand()

ModifyTemplateGridCommand::~ModifyTemplateGridCommand ( )

override

Destructor

ModifyTemplateGridCommand() [2/2]

ModifyTemplateGridCommand::ModifyTemplateGridCommand ( const ModifyTemplateGridCommand &  )

private

Member Function Documentation

addColumn()

ModifyTemplateGridCommand * ModifyTemplateGridCommand::addColumn ( TitleBlockTemplate *  tbtemplate, int  index = -1  )

static

This static method is a convenience to create a ModifyTemplateGridCommand that adds a column to tbtemplate at index.

Parameters

tbtemplate	Modified title block template.
index	Index where the column should be inserted.

Returns

a ModifyTemplateGridCommand object, or 0 if something went wrong.

Here is the call graph for this function:

Here is the caller graph for this function:

addRow()

ModifyTemplateGridCommand * ModifyTemplateGridCommand::addRow ( TitleBlockTemplate *  tbtemplate, int  index = -1  )

static

This static method is a convenience to create a ModifyTemplateGridCommand that adds a row to tbtemplate at index.

Parameters

tbtemplate	Modified title block template
index	Index where the row should be inserted.

Returns

a ModifyTemplateGridCommand object, or 0 if something went wrong.

Here is the call graph for this function:

Here is the caller graph for this function:

apply()

void ModifyTemplateGridCommand::apply ( bool  undo = false )

private

Here is the call graph for this function:

Here is the caller graph for this function:

cells()

QList< TitleBlockCell * > ModifyTemplateGridCommand::cells

(

)

const

Returns

a list of pointers to cells composing the inserted/deleted row/column.

Here is the caller graph for this function:

deleteColumn()

ModifyTemplateGridCommand * ModifyTemplateGridCommand::deleteColumn ( TitleBlockTemplate *  tbtemplate, int  index = -1  )

static

This static method is a convenience to create a ModifyTemplateGridCommand that removes the column at index from tbtemplate.

Parameters

tbtemplate	Modified title block template.
index	Index of the removed column.

Returns

a ModifyTemplateGridCommand object, or 0 if something went wrong.

Here is the call graph for this function:

Here is the caller graph for this function:

deleteRow()

ModifyTemplateGridCommand * ModifyTemplateGridCommand::deleteRow ( TitleBlockTemplate *  tbtemplate, int  index = -1  )

static

This static method is a convenience to create a ModifyTemplateGridCommand that removes the row at index from tbtemplate.

Parameters

tbtemplate	Modified title block template.
index	Index of the removed row.

Returns

a ModifyTemplateGridCommand object, or 0 if something went wrong.

Here is the call graph for this function:

Here is the caller graph for this function:

dimension()

TitleBlockDimension ModifyTemplateGridCommand::dimension

(

)

const

Returns

the dimension of the inserted/deleted row/column.

Here is the caller graph for this function:

index()

int ModifyTemplateGridCommand::index

(

)

const

Returns

the index of the inserted/deleted row/column

Here is the caller graph for this function:

isInsertion()

bool ModifyTemplateGridCommand::isInsertion

(

)

const

Returns

true if the row/column is inserted, false if it is deleted

redo()

void ModifyTemplateGridCommand::redo ( )

override

Redo the change.

Here is the call graph for this function:

setCells()

void ModifyTemplateGridCommand::setCells

(

const QList< TitleBlockCell * > &

cells

)

Set the cells composing the inserted/deleted row/column.

Parameters

cells

List of pointers to cells composing the inserted/deleted row/column.

Here is the call graph for this function:

Here is the caller graph for this function:

setDimension()

void ModifyTemplateGridCommand::setDimension

(

const TitleBlockDimension &

dimension

)

Set the dimension of the inserted/deleted row/column

Parameters

dimension

Dimension of the inserted/deleted row/column

Here is the call graph for this function:

Here is the caller graph for this function:

setIndex()

void ModifyTemplateGridCommand::setIndex

(

int

index

)

Set the index of the inserted/deleted row/column.

Parameters

index

Index of the inserted/deleted row/column.

Here is the call graph for this function:

Here is the caller graph for this function:

setInsertion()

void ModifyTemplateGridCommand::setInsertion

(

bool

insertion

)

Parameters

insertion

true if the row/column is inserted, false if it is deleted

Here is the call graph for this function:

Here is the caller graph for this function:

setType()

void ModifyTemplateGridCommand::setType

(

bool

type

)

Indicates whether this object inserts/deletes a row or a column.

Parameters

type	true if this object is about inserting/deleting a row, false for a column.

Here is the call graph for this function:

Here is the caller graph for this function:

type()

int ModifyTemplateGridCommand::type

(

)

const

Returns

true if this object is about inserting/deleting a row, false for a column.

Here is the caller graph for this function:

undo()

void ModifyTemplateGridCommand::undo ( )

override

Undo the change.

Here is the call graph for this function:

Here is the caller graph for this function:

updateText()

void ModifyTemplateGridCommand::updateText ( )

private

Update the text describing what the command does.

Here is the caller graph for this function:

Member Data Documentation

cells_

QList<TitleBlockCell *> ModifyTemplateGridCommand::cells_

private

Cells composing the inserted/deleted row/column.

dimension_

TitleBlockDimension ModifyTemplateGridCommand::dimension_

private

width/height of the column/row, which interpretation depends on type_

index_

int ModifyTemplateGridCommand::index_

private

Index of the inserted/deleted row/column.

insertion_

bool ModifyTemplateGridCommand::insertion_

private

type_

bool ModifyTemplateGridCommand::type_

private

true for a row, false for a column

---

The documentation for this class was generated from the following files:

• sources/titleblock/templatecommands.h
• sources/titleblock/templatecommands.cpp
